JIYI P2 FLIGHT CONTROLLER MULITROTOR FLIGHT AND AUTOPILOT SYSTEM

JIYI P2 FLIGHT CONTROLLER MULITROTOR FLIGHT AND AUTOPILOT SYSTEM www.jiyiuav.com Peripheral Supported Multi-rotor Quad I，Quad X;Hexa I, Hexa v, Hexa Y, Hexa IY; Supported Electronic Speed Controller PWM(HW, ZTW,Blheli,SimonK) Maximum output channels 6 Radio Controller recommended PCM or 2.4GHZ,at least 6channels controller(Support Failsafe function for all channels) xternal Receiver Supported SBUS, PPM, PWM Recommended Battery 2S ~ 6S LiPo Operating Temperature 0-60℃ Storage Temperature -40-60℃ Power Consumption <2W Vibration damper <1G (built in damping device) Flight Performance Hovering Accuracy (In GPS Mode) Vertical: ± 0.8m Horizontal: ± 2m Max Tilt Angle 30° Max Yaw Angular Velocity 150deg/s Ascent/Descent ±6/s Maximum Wind Resistance <8m/s (17.9mph/28.8km/h) Built-In Functions Attitude Mode GPS mode Intelligent Orientation Control Mode Failsafe Mode Low Voltage Protection Hardware specification Total Weight Controller：32g GPS/Compass Mode：32g LED/PMU：20g Dimensions Flight Controller：48.0mm×38.0mm×17.5mm GPS/ compass mode：54.8mm (diameter)×15.2mm LED/PMU：30mm×18mm×10.2mm
