- Wingspan: 1900mm (74.8in)
- Length: 1428mm (56.2 in)
- Flying weight: 4600-5000 g
- Wing area: 43,3 dm2
- Wing loading: 105g/dm2
- Wing type: Naca airfoils
- Covering type: Genuine ORACOVER®
- Gear type: Aluminum scale plate (included)
- Spinner size: 70mm  (not included)
- Radio: 6 channel minimum (not included)
- Servo: 7 standard servo: 2 aileron; 2 flap; 1 elevator; 1 rudder; 1 throttle (not included)
- Recommended receiver battery: 4.8-6V / 2000 mAh NiMH (not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: .91 / 2-stroke glow engine  or 15cc gas engine (not included)
- Motor: brushless outrunner 2200 W, 500 KV (not included)
- Gravity CG: 65 mm (2.6 in) Back from  the leading edge of the wing, at the fuselage
- Control throw Ailerons: Low: 11mm up/down, 10% expo; High: 13mm up/down, 10% expo
- Control throw Elevators: Low: 11mm up/down, 12% expo; High: 13mm up/down, 12% expo
- Control throw Rudder: Low: 25mm right/left, 15% expo; High: 40mm right/left, 15% expo
- Control throw Flap: 15-20 mm down
- Experience level: Intermediate
- Plane type: Scale Civilian
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: RIMFIRE .80 (not included)
- Lipo cell: 6 cells / 4000 – 5500mAh (not included)
- Esc: 60-100A (not included)

Feature

- Designed for compatibility with both GP and EP flight
- Covered in genuine ORACOVER®
- Superb flying characteristics, plus an accurate scale outline
- Functional scale cockpit doors with spring-loaded latches
- Functional panel flaps
- Scale outline is enhanced by the lightweight fiberglass cowl
- Bolt-on two-piece wing for easy transport and setup at the field
- High-quality hardware package included

MANUAL DOWNLOAD
